The Brighter Choice
WASHINGTON is an IP54/65 rated wide beam downlight for commercial applications.
The IP54 or IP65 rating makes it suitable for a wide rfange oif applications, including toilets, changing rooms and under-canopy applications.
WASHINGTON is available as a wattage selectable fitting, from 6-20W or with a fixed output of 30W. A full range of dimming, emergency and smart wireless control options is available.
WASHINGTON has a shallow recessed TP(a) rated diffuser, giving a wide beam angle of 100° so that very high levels of uniformity can be achieved easily.
Because WASHINGTON is supplied with a L, E & N loop-in/loop-out piano-key terminal block it is quick to install and does not require a separate junction box.
• Corridors and communal areas
• Changing rooms and under-canopy installations
• Die-cast aluminium bezel, painted white (RAL9003)
• Die-cast aluminium heat-sink and body, painted black
• Polycarbonate opal diffuser, TP(a) rated
• Remote driver with male / female connector for easy installation & maintenance
• 3-pole, loop-in / loop-out piano key terminal block
• 103o beam angle
Wattages, CCT & cut-out
• Selectable 6-15W, 3000K, IP54, 110mm cut-out
• Selectable 6-15W, 4000K, IP54, 110mm cut-out
• Selectable 6-18W, 3000K, IP54, 200mm cut-out
• Selectable 6-18W, 4000K, IP54, 200mm cut-out
• Fixed 30W, 4000K, IP54, 200mm cut-out
• Selectable 7-20W, 4000K, IP65, 200mm cut-out
Emergency
• For M3, self-test and DALI addressable emergency test, order the conversion pack you need from the list oppposite.
• CSDAM3L: Casambi addressable test
• HSDAM3L: HubSense addressable test
Dimming
• DD: Digital Dimming - DALI and Switch Dim
• CF: Corridor Function – dim-to-10%
• CS: Casambi smart wireless control
• HS: HubSense smart wireless control
Mounting disc - available for use with WASHINGTON 200mm cut-out, for installation in apertures up to 235mm dia. listed opposite
