GENERAL INFORMATION
Product Code
NWA6-15/840
Product Range
WASHINGTON
Product Category
Downlights
Fixing Method
Recessed
IP Rating
54
IK Rating
Warranty
7 Years
DIMENSIONS/WEIGHT
Dimensions
W: 0 - H: 0 - DEPTH: 45 - DIAMETER: Ø130
Cut-out Size (mm)
Ø110
Product Weight (kg)
0
Construction
Body Material
PC / Die Cast Aluminium
Body Colour
White
Optical Material
Optical Finish
Termination
Driver Connections
Driver - Integral or Remote
Remote
PACKAGING
Carton Dimensions (mm)
Quantity per Outer Carton
Total Weight incl. Carton (Kg)
LUMINAIRE PERFORMANCE
Energy Rating
C
Luminaire Lumens (lm)
752 / 993 / 1176 / 1389 / 1584 / 1774 / 1979 / 2163
Power Consumption (W)
6 / 8 / 10 / 12 / 14 / 16 / 18 / 20
Efficacy (l.lm/c.W)
118 / 122 / 118 / 116 / 114 / 111 / 111 / 109
Operating Temp. (Min/Max)
-20°C to 25°C
LIGHT SOURCE
Type
LED
Correlated Colour Temp.
4000
Colour Rendering Index (CRI)
>80
Lumen Depreciation
L80 100000
SDCM
<3
ELECTRICAL INPUT
Voltage (V)
220-240V AC
Operating Frequency (Hz)
50/60Hz
Inrush
Drivers per MCB *
Class
Class 2
Power Factor (PF)
>0.9
Cable Entry
ELECTRICAL OUTPUT
Forward Current (mA)
Forward Voltage (Vf)
EMERGENCY DATA
Mode of Operation
Battery Duration
Battery Type
Battery Specification
Ballast Lumen Factor (BLF)
DIMMING
DALI
Switch Dim
Corridor Function
Other
SENSORS
Microwave
PIR
PEC
STANDARDS/APPROVALS
CE / Cert of Conformity
Yes / Yes
Accreditations
BARCODE / E No. / S No.
EAN Number
5056673218940
E Number
S Number
