The Brighter Choice
CAT-R is a lighting panel designed to reduce the waste associated with repeated CAT-A fit-outs that are followed by a CAT-B fit-out and an eventual return to CAT-A.
CAT-R has a modular design, so that each major component can be swapped for an alternative to suit the varied needs of incoming tenants, without having to discard the entire fitting.
Over 3 CAT-A/B cycles, CO₂ savings in excess of 55% can be expected.
CAT-R is assembled in the UK from European-sourced components and is designed on TM66 circular economy principles.
Tenanted commercial offices where a CAT-A fit-out would otherwise be followed by a strip-out and a CAT-B installation
Metal body, powder coated, Semi-gloss white (RAL9016) available in two sizes:
• 600mm x 600mm
• 1200mm x 300mm
Both sizes are available in 4 different styles: Basic, Square, Winged or Acoustic
• Comprised of 3 interchangeable modules – body, LED cassette and driver
• For lay-in installation in 15-24mm exposed T ceilings
• Vossloh Schwabe driver
LED Cassette:
Available on all body sizes and styles, with a snap-fit mounting and plug and play connection. Choose between Opal or Microprismatic UGR <19, with 3000K, 4000K or 5000K options
Drivers:
Prewired with push to fit, toolless terminals. Choose one of the following:
• FO - Fixed Output, wattage selectable
• DD - Digital Dimming (DALI & Switch Dim)
• CS - Casambi smart wireless control
• HS - HubSense smart wireless control
OPTIONS
Emergency – all maintained 3 hours with lithium (LiFePO4) batteries
• For M3, M3 self-test or M3 DALI (DAM3), order one of the conversion packs listed overleaf
Sensor - Optional plug and play sensor fitted in the body. Contact the technical team for more information
