The Brighter Choice
ATLANTA is an IP44 and IK08 rated bulkhead, designed for surface or suspended installation.
It is available in two sizes (300mm and 450mm diameter), each of which is 3-way power selectable and 3-way CCT selectable (3000K, 3500K, 4000K).
ATLANTA is designed for a first-fix/second-fix installation, with the base being fitted first and the detachable light engine installed later.
A stand-out feature of ATLANTA is the (optional) PIR on/off occupancy sensor integrally fitted in the opal diffuser. This is a low cost and unobtrusive way to add PIR control as no additional installation cost or effort is required.
• For light industrial, commercial and residential use
• Toilets, bathrooms, corridors and circulation areas
• For surface or suspended installation
• First-fix polycarbonate base with terminal block and female connector
• Second-fix light engine with LEDs, opal diffuser and male connector
• Selector switches fitted internally for wattage (as listed below) and CCT, 3000K, 3500K and 4000K
Diameter and wattage
Available in two sizes, each with 3 selectable wattages:
• 300mm diameter, 8W, 10W, 12W selectable
• 450mm diameter, 10W, 14W, 18W selectable
Emergency
• M3 Manual test emergency conversion packs with lithium batteries, available as listed below
Sensor
Available with a passive infra-red occupancy sensor fitted, adjustable for:
• Lux: 0-30 lx
• Detection range: 3-8m at 2.5m mounting height
• Time delay: 8 steps, from 2 seconds to 30 minutes
